Core P5 Core P5 Core P5 Core P5 Core P5 Core P5 Core P5
Core P5

Core P5

In stock
SKU
CA-1E7-00M1WN-00
USD$300.00

Thermaltake Core P5 ATX Open Frame panoramic viewing gaming computer case with Tt LCS Certified



Thermaltake Core P5 ATX Wall-Mount Chassis
Take presentation to the next level with the Core P5 Open Frame chassis by Thermaltake. The fully modular design of the Core P5 allows flexibility for 3-way placement layouts (Wall mount, Horizontal and Vertical), dual GPU layout locations: Horizontal and Vertical and placement locations for liquid cooling components. Uncover greatness with the Core P5’s panoramic viewing angle with its large acrylic window to protect and present. Seeing is believing, the Core P5 brings the ultimate in PC hardware viewing wherever you mount or display.

*A standard riser cable is included.
Thermaltake Core P5 Product Animation
The Core P5 ATX Wall-Mount Chassis

Tt LCS Certified is a Thermaltake exclusive certification applied to only products that pass the design and hardcore enthusiasts standards that a true LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.


Built for Makers
By practicing and incorporating the ideas of the “maker movement”, Thermaltake has designed the Core P5. The Core P5 is an an open frame chassis that anyone can access to do his or her own mods. This open frame chassis lets users map out and design their own build featuring whatever components they would like to use.

Users can download design files for the Core P5 on our microsite allowing them to customize their own mods.


Fully Modular Concept
Four customizable 3.5” & 2.5” drive bays enable users to freely interchange the hard-drive cages to suit their particular needs. Users can also remove the 3.5” & 2.5” drive bays to gain maximum space for cable management up to 45mm.

3-Way Placement Layout
The Core P5 wall-mount chassis is designed for use in three different ways: Wall-mount, vertical, and horizontal placement. Built for customization that reflects the makers’ personality, it allows for adjustments to the look of the chassis while ensuring outstanding cooling performance.

Users can hang it on the wall as decoration, take it to wherever they want and display their builds vertically or horizontally.

Panoramic Viewing
Other cases on the market still have “ends” on their open frame designs, while the Core P5 is a true wall-mount case capable of showing the front and back full sides. The Core P5 is unlike anything on the market that is not a modded design or scratch build.


Supreme Liquid-Cooling Support
Core P5 wall-mount chassis enables users to build a complete high-end system, whilst supporting up to either 480mm radiator liquid cooling, or 140mm case fans, with a long graphic card at the same time, and simultaneously providing the best visual effects as well as increasing the CPU’s case modding potential. Most importantly, it has the capability to deliver an outstanding cooling efficiency throughout the entire case.



Versatile GPU & PSU Orientation
Show off your graphic card and power supply with our special design bracket. The Core P5 has included a standard riser cable for you to choose the way you want to build the system. Further, the Core P5 also has the support for vertical PSU layout when ITX motherboard is applied.

Thermaltake TT Premium PCI-E 3.0 Extender (Optional) – Supports a wide range of GPU solutions with ultra-excellent quality. Features like, extreme high-speed cable with highly-routable design, EMI shielding with conducting polymer are crafted for meeting the most demanding system. Available in 300mm, 600mm and 1000mm length.
*Thermaltake makes no representation or warranty that the included standard riser cable will be suitable for any specified computer system without further testing. If you need any technique supports, please contact Thermaltake Global Service Center.


AIO Bracket (Optional)
Make your Core P5 stand out in the crowd. Build it up with the new Thermaltake AIO bracket, designed to support the AIO liquid cooling system and HDD expansion. The Core P5 can hold up to three brackets, and a single AIO bracket can support one 120mm or 140mm fan.


Core P5 Radiator Supporting List
Radiator Compatibility List
  120
mm
140
mm
240
mm
280
mm
360
mm
420
mm
480
mm
L-Side * * * * * * *

Core P5 Fan Supporting List


Thermaltake Fan Compatibility List
  120mm 140mm
Pure Fan Series * *
Luna Fan Series * *
Riing Fan Series * *
※ Optional bracket is available for AIO installment

Core P5 Wall-Mounting Support
It’s an optional feature that wall-mounting parts are not included. See the picture on the left-hand side or download the Core P5 manual under “Support”.
More Information
SKU CA-1E7-00M1WN-00
P/N CA-1E7-00M1WN-00
Series Core
Model Core P5
Case Type Mid Tower
Dimension (H x W x D) 608 x 333 x 570 mm
(23.9 x 13.1 x 22.4 inch)
Net Weight 12.2 kg / 26.9 lb
Side Panel Transparent Window
Color Black
Material SPCC
Expansion Slots 8
Motherboards 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
I/O Port USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
PSU Standard PS2 PSU (optional)
Fan Support Left Side:
4 x 120mm
3 x 140mm
Radiator Support Left Side:
1 x 480mm
1 x 420mm

User Manual

  • File Name
  • Description
  • Size
  • Version
  • Release Date
Tweak Town
2018-12-10

 The Bottom Line: It is very hard to deny the awesomeness of the Core P5 from Thermaltake! With a bit of assembly and hardware installation, this wall hangable open air chassis is a real stunner that anyone can appreciate.

Overall Rating: 99%

<More>
Think Computers
2018-12-10

 Pros:
– Extremely unique case
– Can be used to display your hardware
– Can be wall-mounted
– Can fit a lot of hardware and watercooling

<More>
Bit-Tech
2018-12-10

 "We really weren't sure what to expect with the Core P5, but for a number of reasons we're actually quite fond of it. The build quality is excellent, if a little rough round the edges in places, but the sheer weight and solid feel of the chassis leaves you in no doubt that it's up to the task of housing a large, high-end water-cooled system."

<More>
Tom's Hardware
2018-12-10

Was uns gefallen hat, ist die allgemeine Stabilität, die auch bei sehr schweren verbauten Komponenten nie wirklich an ihre Grenzen kommt. Egal ob es nun eine horizontal augestellte Grafikkarte mit fast 1,4 kg Lebengewicht ist oder ein schweres Netzteil plus dickem, voll befüllten Radiator nebst Ausgleichsbehälter und Gedöns. Sowohl die sehr massiven und recht ordentlich ausbalancierten Standfüße als auch die massive, VESA-kompatible Befestigungsmöglichkeit im Rahmen setzen der Auswahl des Standorts für das Core P5 kaum Grenzen. Es steht oder hängt, aber wankt und wackelt nie.

<More>
Hardwareluxx
2018-12-10

 Positive Aspekte des Thermaltake Core P5:

  • auffälliges Show-Gehäuse zu einem moderaten Verkaufspreis
  • kann stehend, liegend oder hängend genutzt werden
  • für die Nutzung einer leistungsstarken Wasserkühlung optimiert
  • genug Platz für ein High-End-System
  • Kabel können bei ausreichender Länge hinter dem Tray versteckt werden
  • I/O-Panel mit vier USB-Ports
<More>
TechnologyX
2018-12-10

"There’s no doubt that the Core P5 is one of the most fun builds we have had the pleasure to do...  There is very little downside to purchasing the P5, maybe making it more suitable for pre-assembled basic cooling systems would be beneficial. However, the good far outdoes the bad. The perfect placement and number of pass-through ports impressed us. A 480mm cooling system and vertical installation of the GPU are outstanding. Not to mention the option to wall mount. This open air concept has hands down earned out Editors Choice."

<More>
Modding.fr
2018-12-10

Les points positifs +



  • Look original
  • Finition
  • Assemblage
  • Baie vitrée
  • Rangement des câbles
  • Watercooling
  • Debout, couché ou au mur
  • Riser blindé
  • Prix
<More>
HardOCP
2018-12-10

The Thermaltake Core P5 is a very unique case that gives the end user a great opportunity to flaunt their system building prowess. This chassis truly is a showstopper that turns your PC into a conversation piece and any work space into a showcase for your system build.

<More>
Hardware Inside
2018-12-10

 Positiv
+ Gute Verarbeitungsqualität
+ Optionale Wandmontage
+ Als Show-Case einsetzbar
+ 90 Grad gedrehter Grafikkarteneinbau möglich
+ Versteckte Plätze für Festplatten und SSDs
+ Platz für einen Radiator bis zu einer Länge von 480 mm
+ Seitliche Anschlüsse (HD-Audio, 2x USB 2.0, 2x USB 3.0)

<More>
OCaholic
2018-12-10

"The Thermaltake Core P5 is an excellent solution for modders and gamers who want to show off their PC. We are aware that some manufacturers / modders are creating similar layouts but only for more advanced users. Thermaltake Core P5 is perfect for everyone since it does not require any special skills for the mounting process. Installing the components and parts is quite intuitive..."

<More>
hwlegend.com
2018-12-10

Dopo aver provato con molta soddisfazione il Core X9, Thermaltake è riuscita di nuovo a stupirci, creando un prodotto decisamente interessante, che porta una ventata di novità nel settore dei cabinet da pc. Il Core P5 unisce la praticità di un banchetto tradizionale con la bellezza di un cabinet moderno, il tutto con un eleganza senza pari.

  • Ottimi materiali utilizzati;
  • Bundle completo;
  • Filtro antipolvere magnetico inclusi;
  • Ottimo spazio all’interno per la gestione dei componenti hardware;
  • Ottima aerazione interna;
  • Supporto per schede video lunghe fino a 320mm;
  • Supporto per un radiatore da 480mm;
  • Supporto per dissipatori a torre alti fino a 180mm;
  • Supporto per un alimentatore in formato ATX (max 200mm);
  • Compatibilità schede madri Mini ITX, Micro ATX, ATX e E-ATX;
  • Possibilità di montaggio in tre differenti modi.
<More>
Nikktech
2018-12-10

 PROS


- Build Quality
- Design
- Wall Mount, Vertical & Horizontal Placement
- Open-Air Chassis
- Supports 240/280/360/420/480mm Radiator
- Reservoir/Pump Mounting Spot
- Room For Up To 6 Drives
- Space For 180mm Tall CPU Coolers & 320mm Long Graphics Cards
- Price (Compared To Its Competition)

<More>
Modders-Inc
2018-12-10

"Thermaltake took to “Thinking outside of the box” to heart with the CORE P5. The minimalist approach to the chassis is what helps make this an eye catching piece. They took the time to see what was really needed when building a PC then tailored that to the concept they had. By taking a design chance they achieved was a design that has been very successful for then and something that the casual PC builder wanted to help take their personal computer to the next level with minimal effort..."

<More>
Mod Zoo
2018-12-10

 Pros:

  • Great design
  • Lots of options included
  • Ample HDD and SSD support
  • Vertical GPU mount
  • Included PCIe riser cable
  • Great build quality
  • Support for up to a 480mm or a 420mm radiator
  • Build in reservoir mounting holes
  • Included pump mount



<More>
i2Hard
2018-12-10

Плюсы:

  • Инновационный дизайн;
  • Комплект поставки;
  • Возможность установки корпуса вертикально, горизонтально и на стену;
  • Эффективность охлаждения;
  • Большое пространство для кабеля менеджмента;
  • Совместимость с любыми габаритными комплектующими;
  • Широкие возможности при построении сборки с СЖО;
  • Доступная цена.
<More>
