Smart DPS G 700w Bronze

Smart DPS G 700w Bronze

In stock
SKU
PS-SPG-0700DPCBXX-B
USD$99.99

Smart Series SPG-0700D-B – 700W 80 PLUS® Bronze Certified Semi-Modular APFC PSU



More Information
SKU PS-SPG-0700DPCBXX-B
P/N PS-SPG-0700DPCBXX-B
watts 700W
RGB Fan No
Form Factor ATX
Model SPG-700DH2CCB
Type Intel ATX 12V 2.31 & SSI EPS 12V 2.92
Max. Output Capacity 700W
Peak Output Capacity 840W
Color Black
Dimension ( W / H / D ) 150mm(W) x 86mm(H) x 140mm(D)
PFC (Power Factor Correction) Active PFC
Power Good Signal 100-500 msec
Hold Up Time > 10msec at 80% of full load (230Vac input)
Input Frequency Range 47Hz - 63Hz
Input Voltage 100V - 240V
Operating Temperature 0 ℃ to +40℃
Operating Humidity 20% to 90%,non-condensing
Storage Temperature

-20 ℃ to +70 ℃

Storage Humidity 5% to 95%, non-condensing
Cooling System 12cm dual ball bearing Fan
Efficiency MEET 80 Plus Bronze at 115Vac input.
MTBF 120,000 hrs minimum
Safety Approval CE/FCC/UL/TUV/CB/EAC/BSMI
Protection OPP, OVP, UVP,OTP

User Manual

  • File Name
  • Description
  • Size
  • Version
  • Release Date

Drivers & Software

  • File Name
  • Description
  • Size
  • Version
  • Release Date
  • DPS G App
  • MD5: 5672038287e2e81467434efe6fb0ad6e
  • V3.1.7
  • 2019-05-22
  • Fix Tool
  • If DPS G App opens twice after boot up, download the tool to fix the issue.
    *Please right-click the software and run it in administrator mode.
  • 201
  • 1.0
  • 2018-11-01
EL CHAPUZAS
2018-12-18

Las fuentes de alimentación Thermaltake Smart DPS G destacan sobre todo por su cableado semi-modular por hilos y por la posibilidad de monitorizar multitud de paramentos por software en tiempo real. Con una certificación 80+ Bronce garantizan una eficiencia bastante correcta, por lo que se adaptan a los que buscan una buena fuente sin comerse demasiado la cabeza con el consumo, que no será mucho más elevado que en modelos tope de gama.

<More>
