Toughpower DPS G RGB 1250W Titanium
Toughpower Series TPG-1250D-T – 1250W 80 PLUS® Titanium Certified Fully Modular APFC PSU
The Thermaltake Toughpower DPS G RGB 1250W Titanium is the world’s first PSU
pre-installed with a patented 256 colors RGB fan that incorporate various high-tech
components, leading technology and Eco-friendly commendations. Featuring 80 PLUS
Titanium certification with individually sleeved cable and flat cable, Toughpower
DPS G RGB Titanium Series adopts the highest quality components and fully modular
design that always accommodate any mainstream build under any circumstance.
The combination of Toughpower DPS G RGB Titanium and three intelligent platforms – DPS G PC APP 3.0, DPS G Smart Power Management (SPM) Cloud 1.0, and DPS G Mobile APP 1.0 helps users not just monitor smart power supply units, but also save the energy, reduce CO2 emission, and eventually protect the Earth.
Smart Power Management (SPM) is a cloud-based software that seamlessly integrates three
intelligent platforms – DPS G PC APP 3.0, DPS G Smart Power Management Cloud 1.0 and DPS
G Mobile APP 1.0 – and compiles key statistics about your PC into detailed charts and
breakdowns for your instant PC status view and management. With easy access to SPM
through your PC or mobile devices, whether you are outside or indoors, enjoy taking full
control of your build anytime, anywhere!
Smart Zero Fan
Toughpower DPS G RGB Series comes with Smart Zero Fan, which is activated
through DPS G PC APP 3.0 and will turn on the fan on around 30% of rated
load to minimize the audible noise of your PC and optimize the thermal
The SPM platform comes with real-time warning alert function, which will appear on your DPS G Mobile APP/DPS G Smart Power Management Cloud and also your email when fan failure, PSU over temperature (over 140℉/60℃), or abnormal voltage level (over/under 5% of normal level) occurs. Then users can shut down their PC remotely to avoid further damage.
Save PC energy and electricity cost by scheduling your PC to shutdown at any time you
want through DPS G Mobile APP or DPS G Smart Power Management Cloud.
※The photo is for reference.
The first RGB PSU series introduced by Thermaltake install with a patented circular 256 multi-colored 140mm fan. Users can freely adjust fan speed as well as fan colors digitally through DPS G PC App. The app features four lighting modes: Single Color, Random Color, RGB Cycle, and Blink. The color and brightness uniformity of the multicolored LED ring is visible from all directions and adds style to the chassis.
By face-up placement, users can adjust the PSU with patented circular 256
multi-colored RGB fan for the best viewing presentation while ensuring outstanding
cooling performance. As the thermal image testing shown, the temperature of PSU and
computer system will decrease around 3°C (5.4 °F) by placing PSU face-up.
The fan blade is designed for high static pressure requirements of demanding applications; the concentrated compression blade is engineered to focus the weaker, inner circle of air outward, allowing the outer section to pressurize the air. The fan blades are optimized to enhance static pressure for an impressive cooling performance. Hydraulic bearings for silent operation guarantee ultra-low noise, and the anti-vibration mounting system strengthens the product’s stability during operation. Moreover, In-mold injection anti-vibration rubber pads provide hassle-free usage for 80% protection coverage, including all four corners.
The Toughpower DPS G RGB 1250W Titanium features 100% high quality Japanese brand
capacitors, which greatly improves the durability and offers the highest stability
Fully modular power supply offers cable selection for users while powering the system at an advantageous voltage. Individually sleeved cable and flat cable can make cable management easier, reduce clutter and increase airflow inside the chassis.
Toughpower DPS G RGB 1250W Titanium Series comes with a 32Bit Microcontroller Unit (MCU) from Microchip Technology. The 32Bit MCU is a small computer on a single integrated circuit containing a processor core, memory, and programmable input/output peripherals. MCU can digitally control devices and processes, such as automobile engine control systems and office machines.
Digital power supplies support high-efficiency switching transistors that perform only necessary steps and waste less energy given off as heat. In short, digital power supplies do not dissipate power, which creates waste, and incorporate smaller, lighter transistors. Using smaller parts that work more efficiently enables Thermaltake to craft smaller and lighter power supplies, typically one of the bulkiest components in any PC.
Toughpower DPS G RGB 1250W Gold is equipped with a powerful single +12V rail, please
see the output specification below:
Toughpower DPS G RGB 1250W Titanium Power Supply with DPS G software delivers up to 94% efficiency under real-world load conditions, promising the lowest power losses. Additionally, Toughpower DPS G RGB 1250W Titanium has been optimized to work with Intel’s new, Seventh-generation Kaby Lake processors to achieve maximum energy savings.
Toughpower DPS G RGB Series power supplies offer stable and sufficient output voltage for multiple VGA cards and high Capability of different VGA cards for VR system.
|Type||Intel ATX 12V 2.31 & SSI EPS 12V 2.92
|Max. Output Capacity||1250W
|Peak Output Capacity||1500W|
|Dimension ( W / H / D )||150mm(W) x 86mm(H) x 200mm(D)|
|PFC (Power Factor Correction)||Active PFC|
|Power Good Signal||100-500 msec|
|Hold Up Time||> 16msec at 100% of full load (115Vac/ 230Vac input)
|Input Frequency Range||47Hz - 63Hz|
|Input Voltage||100V - 240V|
|Operating Temperature||0 ℃ to +50℃|
|Operating Humidity||20% to 90%,non-condensing|
|Storage Temperature||-20 ℃ to +70 ℃|
|Storage Humidity||5% to 95%, non-condensing|
|Cooling System||14cm RGB Fan|
|Efficiency||MEET 80 Plus Titanium at 115Vac input|
|MTBF||120,000 hrs minimum|
|Safety Approval||CE/FCC/UL/ TUV/EAC|
- File Name
- Release Date
Drivers & Software
- File Name
- Release Date
I come to the end of this review asking myself if Thermaltake's new flagship unit has what it takes to match wits with the other big deal top of the line units on the market. It's giving up some power to the EVGA and Corsair competition, and attempting to make up for it by adding features like the color changing fan. This is currently one of only two units that offer both a software interface and Titanium efficiency in the same package. That's hard to do. The problem is... Corsair's done it just a bit better from a performance standpoint. And yet, this is definitely the better looking unit to me. And the performance difference really isn't all that great. I guess what I'm saying is... I don't know which of these kids is my favorite. You're all special to Daddy.<More>
This year’s show was packed full of great new products, but few brands brought as many new toys to the show as Thermaltake. Even with so much to show off this year, there was one product in particular that really stood out for us in the Thermaltake suite, the Thermaltake ToughPower DPS G RGB 1250W Power Supply.<More>
